Lenovo ThinkSystem SR645 V3 1U Rack Server with AMD EPYC 9004 Genoa

Name: Lenovo ThinkSystem SR645 V3 1U Rack Server with AMD EPYC 9004 Genoa
Brand: Beijing Guangtian Runze Technology Co., Ltd.
Price: 210.00 USD
Availability: InStock

Product Details

Payment & Shipping Terms

Minimum Order Quantity: 2 pieces

Price: CN¥16,405.21/pieces

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Lenovo ThinkSystem SR645 V3 server, 1U rack server AMD EPYC, Lenovo GPU server Genoa


Private Mold:	NO	Products Status:	Stock
Type:	Rack	Processor Main Frequency:	2.8GHz
Processor Type:	Intel Xeon	Brand Name:	Le-novo
Model Number:	SR645V3	Place Of Origin:	Beijing, China
Model NO.:	SR645V3	Form Factor:	1U Rack Server
Processor:	2x 4th Gen AMD EPYC Processors	Memory:	Up To 6TB
Internal Storage:	10x 2.5" SAS/SATA/NVMe,10x 2.5" SAS/SATA/NVMe	RAID:	8-port And 16-port RAID Adapters With Up To 8GB Flash
Networking:	OCP 3.0 Slot With PCIe X16 Interface (rear Or Front Of Server)	PCIe:	Up To 5x PCIe Slots (3 Rear, 2 Front)
Power:	500W, 750W, 1100W, 1800W AC Platinum/Titanium Hot Plug PSU	Management And Security:	Integrated XClarity Controller 2

Private Mold:	NO
Products Status:	Stock
Type:	Rack
Processor Main Frequency:	2.8GHz
Processor Type:	Intel Xeon
Brand Name:	Le-novo
Model Number:	SR645V3
Place Of Origin:	Beijing, China
Model NO.:	SR645V3
Form Factor:	1U Rack Server
Processor:	2x 4th Gen AMD EPYC Processors
Memory:	Up To 6TB
Internal Storage:	10x 2.5" SAS/SATA/NVMe,10x 2.5" SAS/SATA/NVMe
RAID:	8-port And 16-port RAID Adapters With Up To 8GB Flash
Networking:	OCP 3.0 Slot With PCIe X16 Interface (rear Or Front Of Server)
PCIe:	Up To 5x PCIe Slots (3 Rear, 2 Front)
Power:	500W, 750W, 1100W, 1800W AC Platinum/Titanium Hot Plug PSU
Management And Security:	Integrated XClarity Controller 2

Lenovo ThinkSystem SR645 V3 1U Rack Server with AMD EPYC 9004 Genoa

Product Description

Specification

Components	Specification
Machine types	7D9D - 1 year warranty 7D9C - 3 year warranty
Form factor	1U rack.
Processor	One or two AMD EPYC 9004 Series processors (formerly codenamed "Genoa"). Supports processors up to 128 cores, core speeds of up to 4.1 GHz, and TDP ratings of up to 360W. Supports PCIe 5.0 for high performance I/O.
Memory	24 DIMM slots with two processors (12 DIMM slots per processor). Each processor has 12 memory channels, with 1 DIMM per channel (DPC). Lenovo TruDDR5 RDIMMs, 3DS RDIMMs, and 9x4 RDIMMs are supported, up to 4800 MHz
Memory maximum	Up to 6TB with 24x 256GB 3DS RDIMMs
Memory protection	ECC, SDDC, Patrol/Demand Scrubbing, Bounded Fault, DRAM Address Command Parity with Replay, DRAM Uncorrected ECC Error Retry, On-die ECC, ECC Error Check and Scrub (ECS), Post Package Repair
Disk drive bays	Up to 4x 3.5-inch or 12x 2.5-inch hot-swap drive bays: * Front bays can be one of the following: * 4x 3.5-inch hot-swap SAS/SATA, AnyBay, or 2x SAS/SATA + 2x NVMe * 2x 2.5-inch hot-swap NVMe * 4x 2.5-inch hot-swap SAS/SATA, AnyBay or NVMe * 8x 2.5-inch hot-swap SAS/SATA * 10x 2.5-inch hot-swap SAS/SATA, AnyBay or NVMe, or combinations * 16x E1.S hot-swap EDSFF NVMe * Rear can be one of the following: * 2x 2.5-inch hot-swap SAS/SATA bays * 2x 2.5-inch hot-swap NVMe bays * 2x 7mm 2.5-inch hot-swap SATA bays * 2x 7mm 2.5-inch hot-swap NVMe bays * Internal M.2 module supporting up to two M.2 drives (optional RAID support), for OS boot and drive storage support See Storage configurations for details. AnyBay bays support SAS, SATA or NVMe drives. NVMe bays only support NVMe drives. Rear drive bays can be used in conjunction with 2.5-inch front drive bays. The server supports up to 12x NVMe drives all with direct connections (no oversubscription).
Maximum internal storage	* 2.5-inch drives: * 368.64TB using 12x 30.72TB 2.5-inch SAS/SATA SSDs * 184.32TB using 12x 15.36TB 2.5-inch NVMe SSDs * 28.8TB using 12x 2.4TB 2.5-inch HDDs * EDSFF drives * 122.88TB using 16x 7.68TB EDSFF NVMe SSDs * 3.5-inch drives: * 88TB using 4x 22TB 3.5-inch HDDs * 61.44TB using 4x 15.36TB 3.5-inch SAS/SATA SSDs * 51.2TB using 4x 12.8TB 3.5-inch NVMe SSDs
Storage controller	* Onboard NVMe (no RAID) - 12 drives, each x4 * Onboard SATA (no RAID) - 12 drives * NVMe Retimer Adapter * 12 Gb SAS/SATA RAID adapters * 8, 16 or 32 ports * Up to 8GB flash-backed cache * PCIe 4.0 or PCIe 3.0 host interface * 12 Gb SAS/SATA HBA (non-RAID) * 8-port and 16-port * PCIe 4.0 or PCIe 3.0 host interface
Network interfaces	Dedicated OCP 3.0 SFF slot with PCIe 5.0 x16 host interface, either at the rear of the server (rear-accessible) or the front of the server (front-accessible, PCIe 4.0). Supports a variety of 2-port and 4-port adapters with 1GbE, 10GbE and 25GbE network connectivity. One port can optionally be shared with the XClarity Controller 2 (XCC2) management processor for Wake-on-LAN and NC-SI support. Additional PCIe network adapters supported in PCIe slots.
PCI Expansion slots	Up to 5x slots, 3x at the rear and 2x at the front, plus 1 OCP 3.0 slot. Rear: Up to 3x PCIe slots (2x PCIe 5.0, 1x PCIe 4.0), all with rear access, plus a slot dedicated to the OCP adapter. Slot availability is based on riser selection and rear drive bay selection. Slot 3 requires two processors. Four choices for rear-access slots: * 3x PCIe x16 low-profile slots * 1x PCIe x16 full-height half-length slot + 1x PCIe x16 low-profile slot * 1x PCIe x16 low-profile slot (also supports 2x rear 2.5-inch drive bays) * 2x PCIe x16 low-profile slot (also supports 2x rear 7mm 2.5-inch drive bays) For 2.5-inch front drive configurations, the server supports the installation of a CFF RAID adapter or HBA in a dedicated area that does not consume any of the PCIe slots. Front: The server also supports slots at the front of the server: * 1x PCIe x16 or x8 full-height half-length slot * 1x PCIe x8 low-profile slot * 1x OCP 3.0 slot (mutually exclusive with the OCP slot at the rear) Note: Not all slots are available in a 1-processor configuration. See the I/O expansion for details.
Ports	Front: 1x USB 3.2 G1 (5 Gb/s) port, 1x USB 2.0 port (also for XCC local management), External diagnostics port, optional VGA port. Rear: 3x USB 3.2 G1 (5 Gb/s) ports, 1x VGA video port, 1x RJ-45 1GbE systems management port for XCC remote management. Optional 2nd XCC remote management port (installs in OCP slot). Optional DB-9 COM serial port (installs in slot 3). Internal: 1x USB 3.2 G1 (5 Gb/s) connector for operating system or license key purposes.
Power supply	Up to two hot-swap redundant AC power supplies, 80 PLUS Platinum or 80 PLUS Titanium certification. 500 W, 750 W, 1100 W and 1800 W AC options, supporting 220 V AC. 500 W, 750 W and 1100 W options also support 110V input supply. In China only, all power supply options support 240 V DC. Also available is a 1100W power supply with a -48V DC input.
Dimensions	Width: 440 mm (17.3 in.), height: 43 mm (1.7 in.), depth: 773 mm (30.4 in.).
Weight	Maximum: 20.2 kg (44.6 lb)
