Product Details
Payment & Shipping Terms
Minimum Order Quantity: 2 pieces
Price: CN¥22,824.64/pieces
Private Mold: |
NO |
Products Status: |
Stock |
Type: |
Rack |
Processor Main Frequency: |
2.0GHz |
Processor Type: |
Platinum 8450H |
Model Number: |
R960 |
Place Of Origin: |
Beijing, China |
Model: |
R960 Server |
Place Of Origin: |
China |
Processor Frequency: |
2.0Ghz |
Memory Capacity: |
64GB |
Memory Type: |
RDIMM,4800MT/s |
Storage: |
480GB SSD |
Weight: |
25kg |
Warranty: |
3-Year |
Private Mold: |
NO |
Products Status: |
Stock |
Type: |
Rack |
Processor Main Frequency: |
2.0GHz |
Processor Type: |
Platinum 8450H |
Model Number: |
R960 |
Place Of Origin: |
Beijing, China |
Model: |
R960 Server |
Place Of Origin: |
China |
Processor Frequency: |
2.0Ghz |
Memory Capacity: |
64GB |
Memory Type: |
RDIMM,4800MT/s |
Storage: |
480GB SSD |
Weight: |
25kg |
Warranty: |
3-Year |
Processor | Up to two 3rd Generation Intel Xeon Scalable processors with up to 24 cores per processor |
Chipset | IntelC620A chipset |
Accelerators | Up to three 75 W single-width GPU |
Memory | DIMM Speed Up to 3200 MT/s |
Memory Type | RDIMM LRDIMM NVDIMM Intel Persistent Memory 200 series (BPS) |
Memory Module Slots | 32 DDR4 DIMM slots |
Maximum RAM | RDIMM 2 TB LRDIMM 4TB NVDIMM 128 GB Intel Persistent Memory 200 series (BPS) 8TB |
Front Bays | Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153 TB Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.8 TB Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB |
Rear bays | Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.7 TB |
Internal Controllers | PERC H745, H345, HBA355I, H755, H755N |
External Controllers | PERC H840, HBA355E |
Internal Boot | Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Internal Dual SD Module or Internal USB 3.0 |
Power Supplies | 800 W Platinum AC/240 V Mixed Mode 1100 W Titanium AC/240 V Mixed Mode 1400 W Platinum AC/240 V Mixed Mode 1100 W DC -48 - 60 V Hot plug power supplies with full redundancy option |
Network Options | 2 x 1 GbE LOM and 1 x OCP 3.0 (x8 PCIe lanes) (optional) |
Front Ports | 1 x iDRAC Direct (Micro-AB USB) port 1 x USB 2.0 1 x VGA |
Rear Ports | 1 x USB 2.0 1 x USB 3.0 1 x Serial (optional) 2 x RJ-45 1 x VGA (optional for liquid cooling configuration) |
Slots | Up to 3 x PCIe Gen4 low profile slots (all x16 except one x8 slot with SNAPI I/O option) or 2 x PCIe (Gen4) full height slots |
Video Card | 1 x VGA (optional for liquid cooling configuration) |
Form Factor | 1U rack server |
Dimensions | Height 42.8 mm (1.68 inches)Width 482 mm (18.97 inches) Depth 809 mm (31.85 inches) – without bezel 822.84 mm (32.39 inches) – with bezel |
Weight | 21.2 kg (46.7 lbs) |
Rack Support | ReadyRails II sliding rails with optional cable management arm (CMA) and strain relief bar (SRB) for 4-post racks. |
